Applications:
the product is used for conveying water,oil,gas under normal working condition in the factory,farm,ship,building and family.
Characteristics:
it is flexible,transparent,durable,non-toxic,without order,anti-erosionand adaptable to high pressure condition.by adding colorful symbol lines on the surface of the hose,it looks more beautiful.
Working temperature: -5℃-+65℃
PVC Fiber Reinforced Hose
British Size | Metric Measurement | W.P. | B.P. | Weight | Packing Size | Volume | ||
At 23℃ | ||||||||
Inch | I.D.mm | O.D.mm | Mts/roll | MPa | MPa | KG/roll | D×Hmm | m3 |
13/64" | 5 | 9 | 170 | 1.2 | 3.6 | 10 | 420×130 | 0.023 |
1/4" | 6 | 10 | 146 | 1.2 | 3.6 | 10 | 430×135 | 0.025 |
6 | 11 | 110 | 1.2 | 3.6 | 10 | 400×150 | 0.024 | |
6 | 12 | 87 | 1.2 | 3.6 | 10 | 400×150 | 0.024 | |
5/16" | 8 | 12 | 117 | 1.2 | 3.6 | 10 | 440×150 | 0.029 |
8 | 13 | 89 | 1.2 | 3.6 | 10 | 425×145 | 0.026 | |
8 | 14 | 71 | 1.2 | 3.6 | 10 | 420×145 | 0.025 | |
3/8" | 9 | 13 | 106 | 1.1 | 3.5 | 10 | 430×150 | 0.027 |
9 | 14 | 81 | 1.1 | 3.5 | 10 | 425×150 | 0.027 | |
13/32" | 10 | 14 | 98 | 1.1 | 3.5 | 10 | 440×150 | 0.03 |
10 | 15 | 75 | 1.1 | 3.5 | 10 | 425×155 | 0.028 | |
10 | 16 | 60 | 1.1 | 3.5 | 10 | 430×140 | 0.026 | |
1/2" | 12 | 16 | 167 | 0.8 | 2.4 | 20 | 560×180 | 0.056 |
12 | 17 | 129 | 0.8 | 2.6 | 20 | 560×200 | 0.062 | |
12 | 18 | 104 | 0.9 | 2.8 | 20 | 560×185 | 0.058 | |
1/2" | 13 | 17 | 156 | 0.8 | 2.4 | 20 | 560×195 | 0.061 |
13 | 18 | 121 | 0.8 | 2.5 | 20 | 570×190 | 0.062 | |
13 | 19 | 98 | 0.9 | 2.8 | 20 | 560×200 | 0.063 | |
35/64" | 14 | 19 | 114 | 0.8 | 2.4 | 20 | 560×210 | 0.066 |
14 | 20 | 92 | 0.8 | 2.4 | 20 | 540×220 | 0.064 | |
5/8" | 15 | 19 | 138 | 0.8 | 2.4 | 20 | 630×195 | 0.077 |
15 | 20 | 107 | 0.8 | 2.5 | 20 | 580×220 | 0.074 | |
15 | 21 | 87 | 0.9 | 2.8 | 20 | 580×220 | 0.074 | |
16 | 20 | 130 | 0.7 | 2.1 | 20 | 580×220 | 0.074 | |
16 | 21 | 101 | 0.7 | 2.2 | 20 | 580×220 | 0.074 | |
16 | 22 | 82 | 1 | 3.5 | 20 | 570×205 | 0.067 | |
45/64" | 18 | 24 | 75 | 0.8 | 2.4 | 20 | 570×195 | 0.063 |
3/4" | 19 | 23 | 112 | 0.6 | 1.8 | 20 | 640×215 | 0.088 |
19 | 24 | 87 | 0.7 | 2.3 | 20 | 600×210 | 0.076 | |
19 | 25 | 71 | 0.8 | 2.5 | 20 | 580×210 | 0.07 | |
19 | 26 | 59 | 0.9 | 2.7 | 20 | 570×210 | 0.068 | |
25/32" | 20 | 25 | 83 | 0.7 | 2.1 | 20 | 615×210 | 0.079 |
20 | 26 | 68 | 0.7 | 2.3 | 20 | 610×185 | 0.069 | |
20 | 27 | 57 | 0.8 | 2.5 | 20 | 590×210 | 0.073 | |
55/64" | 22 | 30 | 46 | 0.8 | 2.5 | 20 | 580×220 | 0.074 |
1" | 25 | 29 | 87 | 0.4 | 1.2 | 20 | 640×230 | 0.094 |
25 | 30 | 69 | 0.5 | 1.5 | 20 | 640×230 | 0.094 | |
25 | 31 | 56 | 0.6 | 1.8 | 20 | 650×220 | 0.093 | |
25 | 32 | 47 | 0.6 | 1.8 | 20 | 610×250 | 0.093 | |
1-1/4" | 32 | 38 | 67 | 0.5 | 1.5 | 30 | 770×229 | 0.136 |
32 | 39 | 57 | 0.5 | 1.5 | 30 | 770×230 | 0.136 | |
32 | 40 | 49 | 0.6 | 1.8 | 30 | 760×290 | 0.167 | |
32 | 41 | 43 | 0.6 | 2 | 30 | 750×250 | 0.14 | |
1-1/2" | 38 | 45 | 48 | 0.5 | 0.5 | 30 | 770×240 | 0.142 |
38 | 46 | 42 | 0.5 | 0.5 | 30 | 770×240 | 0.142 | |
38 | 47 | 37 | 0.6 | 0.6 | 30 | 780×280 | 0.17 | |
1-3/4" | 45 | 55 | 47 | 0.5 | 1.5 | 50 | 960×340 | 0.313 |
2" | 50 | 58 | 54 | 0.4 | 1.2 | 50 | 980×240 | 0.23 |
50 | 59 | 48 | 0.5 | 1.5 | 50 | 980×240 | 0.23 | |
50 | 60 | 43 | 0.5 | 1.5 | 50 | 980×240 | 0.23 | |
50 | 61 | 38 | 0.6 | 1.8 | 50 | 930×380 | 0.33 | |
50 | 62 | 35 | 0.6 | 1.8 | 50 | 930×380 | 0.33 | |
